90 Min. Galvanized 16ga. Adjustable Masonry Double Door Frames

Commercial Steel Frames » 90 Min. Galvanized 16ga. Adjustable Masonry Double Door Frames

90 Min. Galvanized 16ga. Adjustable Masonry Double Door Frames

click for larger image
90 Min. Galvanized 16ga. Adjustable Masonry Double Door Frames
[HMM-ADJ-DBL]

Back order until May 2012

Starting At: $199

HEIGHT

PART #

FRAME DEPTH

THROAT SIZE

SALE PRICE

80” (6/8)

HMM-ADJ-DBL

5-5/8” to 8-3/4”

4-3/4” to 7-7/8”

$199.00

84” (7/0)

HMM-ADJ-DBL

5-5/8” to 8-3/4”

4-3/4” to 7-7/8”

$209.00

96” (8/0

HMM-ADJ-DBL

5-5/8” to 8-3/4”

4-3/4” to 7-7/8”

$219.00

STEEL FRAME PREP OPTIONS:

ITEM CODE

DESCRIPTION

PRICE

LOCK & LATCH HARDWARE PREP

[STF-DBLH]

DEADBOLT PREP 5-1/2" CENTER TO CENTER LEFT HAND FOR STEEL FRAMES

$15.00

[STF-DBRH]

DEADBOLT PREP 5-1/2" CENTER TO CENTER RIGHT HAND FOR STEEL FRAMES

$15.00

[STF-FB]

FLUSH BOLT PREPPED HEADER FOR STEEL FRAMES

$18.00

[STF-ESTRIKE]

ELECTRONIC STRIKE PREP FOR STEEL FRAMES (TEMPLATE #:___________)

$66.00

[STF-BLANKST]

BLANK OUT STRIKE FOR STEEL FRAME FOR STEEL FRAMES

$23.00

[STF-SVR]

SURFACE MOUNTED  VERTICAL ROD STRIKE PREP FOR STEEL FRAMES

$18.00

[STF-CVR]

CONCEALED  VERTICAL ROD STRIKE PREP FOR STEEL FRAMES

$18.00

[STF-RIM]

RIM PANIC REINFORCEMENT PREP FOR STEEL FRAMES

$15.00

HINGE & CLOSER/COORD. HEADER PREP

[STF-REHINGE]

HINGE RELOCATION FOR STEEL FRAMES

$23.00

[STF-CONTHIN]

CONTINUOUS HINGE PREP FOR STEEL FRAME

$38.00

[STF-EHINGE]

ELECTRONIC HINGE PREP FOR STEEL FRAME (PER HINGE)

$18.00

[STF-COORD]

REINFORCEMENT TO STEEL FRAME HEAD FOR DOOR COORDINATOR

$23.00


Features

HMD

Label: Warnock Hersey 3 Hour Fire Label

Specifications:
  • 16 Gauge cold rolled steel knocked down-frames
  • 4-1/2” universal Hinge Template
  • 4-7/8” ASA Strike Prep
  • For 1-3/4” Doors
Hinge Locations: AMWELD
Application: Masonry
Anchors: Recommended T Strap or Wire Strap Anchors (additional)



Special Orders: Other Sizes Can Be Special Ordered.

INSTALLATION INSTRUCTIONS

STEEL FRAME & HW SELECTION GUIDE
